1.The radiator is 6063 aluminum, which adopts thick anti-corrosion paint treatment.
2.No additional wiring is required, saving costs, multiple mounting brackets can be tube mounted.
3.High light transmission PC protective cover of more than 90%, high light efficiency.
4.High charging efficiency up to 95%. MPPT controller is automatically adjust the output power according to weather changing.
5.Using Lumileds SMD 2835 led chips, high luminous efficiency up to 180lm/w, low luminous decay, high energy-saving.
6.High thermal conductivity aluminum substrate and radiator, low temperature rise, good heat dissipation of the whole lamp, and more guaranteed life.
Product Model | ES-LK-100W | ES-LK-120W |
Product Size | 1310*528*50mm | 1490*528*50mm |
Power | 100W | 120W |
Solar Panel | 36V/120W Mono-crystalline | 36V/150W Mono-crystalline |
Solar Panel Size | 1300*500mm | 1470*500mm |
Battery | LiFePO4 Lithium battery 24V,30AH (720WH) | LifePO4 Lithium battery 24V,36AH (864WH) |
Material | 6063 aluminum + PMMA Lens | 6063 aluminum + PMMA Lens |
LED Chip | Lumileds SMD 2835/3030 | Lumileds SMD 2835/3030 |
Luminous Efficiency | 180lm/w | 180lm/w |
Lumen | 18000lm | 21600lm |
Controller | MPPT controller | MPPT controller |
Lighting Method | Auto On/Off + Microwave Induction + Time Control + Intelligent Control | |
Charge Time | 4-6 Hours | |
Temperature | -30℃-+55℃ | |
Lifetime | 50,000 hours | |
Beam Angle | TYPE II, TYPE III, TYPE IV, TYPE V | |
IP Grade | IP65 | |
Warranty | 3 years | |
Package | Support customized company logo and package, OEM & ODM are available | |
Gross Weight | 26KG | 28.5KG |
