Lamp Power

30W-60W

80W-120W

150W-180W

200-250W

300W-320W

LED Qty

72/96/144pcs

108/144/216pcs

180/240/360pcs

240/320/480pcs

384/576pcs

Lamp size(mm)

588X210X110

 600X258X110

700X258X110

705X308X110

788X335X115

Pole Diameter

φ60mm

φ60mm

φ60mm

φ60mm

φ60mm

Raw Material

Die-cast Aluminum+PC Lens+Glass

Beam Angle

60°/90°/120°/T2M/T3M

Lamp Efficiency

120-130LM/1W; 140-150LM/1W; 160-170LM/1W

LED Color

3000-3500K; 4000-4500K; 5000-5500K; 6000-6500K

CRI

Ra＞70 / 80

LED Driver

Inventronics/MeanWell/Philips/MOSO or Others

Power Factor

＞0.95

IP Grade

IP65

Life Time

50000H/100000H

SPD

4KV-6KV-10KV-20KV

Input Voltage

AC90-305V   50/60Hz

Body Color

Black or Grey

Available Option

NEMA Socket(3/5/7pins), Short Cap, Photocell, Motion Sensor, Knife Switch, DALI Dimming, NTC, OLC, Solar Compatible

Certificate

CB, BIS, SASO, CE-LVD-EMC, RoHs, IES, TUV, EAC, ISO9001, SAA, Intertek TIR
